BigFoot 12-Inch Carbon Fiber Block Wall Repair Kit — The Widest DIY Strap for CMU and Cinder Block Foundations
60 ft of 12-Inch 300GSM Unidirectional Carbon Fiber — Built for Block Walls, Mortar-Joint Failure, and Severe Bowing
This is the wide-strap kit for the hardest walls. Where the standard 8-inch kit handles poured concrete and routine cracking, the 12-inch BigFoot strap is engineered specifically for concrete block (CMU) and cinder block foundations — the hollow-core walls that fail at their mortar joints and need the load spread across the widest possible bonding area. If your block wall is bowing, cracking in a stair-step pattern, or the block itself is weak or weathered, this is the kit built for it.
Bowed CMU block and cinder block foundation walls
Stair-step cracking along mortar joints
Weak, weathered, or deteriorated block needing maximum bond area
Window-opening reinforcement and corner repair
12-inch width spreads load over 50% more surface than an 8-inch strap
300GSM unidirectional fiber, 4,100 MPa tensile — third-party ASTM tested
Limited Lifetime Warranty
Free NextStar Technical Support — 1-866-445-3984
Low-cost ground shipping USA & Canada
8-Inch vs 12-Inch — Which Carbon Fiber Width Does Your Wall Need?
The right strap width comes down to your wall type and condition. Wider is not automatically better — it is matched to how the wall fails. Block walls fail at the mortar joints and need the load spread wide; solid poured walls do not.
| Your wall |
Recommended strap |
Why |
| CMU block, cinder block, weak or weathered block |
This kit — 12-inch BigFoot |
Hollow cores and mortar joints need the widest bond area to prevent debonding |
| Sound poured concrete, standard vertical or horizontal cracks |
8-inch DIY kit → |
Solid wall is strong enough for an 8-inch strap; no need for extra width |
| Concentrated high-load bow on poured concrete |
6-inch 600GSM bulk → |
Maximum fiber density in a narrow footprint on sound concrete |
Not sure which your wall needs? Call 1-866-445-3984 and we will size it with you — no charge.
How Much Wall Does the 60ft BigFoot Kit Cover?
The kit supplies 60ft of uncut 12-inch carbon fiber, cut to your own wall height. Straps install 4ft in from each corner, then every 4ft on-center. Because each strap runs floor to sill, your strap count depends on ceiling height:
- 8ft block walls: about 7 full-height straps
- 9ft block walls: about 6 full-height straps
- Shorter walls: more straps
Divide 60 by your wall height to estimate strap count, then confirm it covers your wall length at 4ft spacing. Need more? Extend to 75ft at checkout for longer or full-perimeter block walls.
Kit Components — 12-Inch BigFoot Block Wall Repair Kit
60 ft of 12-Inch 300GSM Unidirectional Carbon Fiber:
Supplied in an uncut roll — cut to your strap lengths with sharp scissors on any flat surface. Enough for approximately 6 to 7 full-height straps depending on wall height.
6 Quarts of StarTech Carbon Fiber Saturation Epoxy:
Professional-grade two-part epoxy formulated to fully saturate and bond unidirectional carbon fiber to concrete and block.
Application Accessories:
1 tray, rollers, gloves, and miscellaneous items for epoxy application.
10 Concrete Anchors:
For securing carbon fiber fabric during installation.
4.5 Inch Diamond Concrete Cup Wheel:
For grinding and preparing the block surface at each strap location prior to epoxy application.
Complete Instructions & Free Technical Support:
Step-by-step guide and access to NextStar's technical support team at 1-866-445-3984.
Available Options
Extend to 75ft of carbon fiber — for longer or full-perimeter block walls. Add $225.00 USD at checkout.
Upgrade to 5-inch diamond cup wheel — for larger grinders. Add $20.00 USD at checkout.
Optional top and bottom wall anchors — block walls in particular benefit from anchoring the strap to the sill plate at the top and pinning the bottom course at the footing. These engage the full tensile strength of the fiber on walls showing top-of-wall movement or a footing that has shifted. Ask about anchor options when ordering.
Why Block Walls Need the 12-Inch Strap
Concrete block and cinder block walls fail differently than poured concrete, and that difference is the whole reason this kit exists. A poured wall is solid through its full thickness and bends as one monolithic unit. A block wall is hollow — its strength depends entirely on the mortar joints between courses. When hydrostatic soil pressure and freeze-thaw cycles push on a block wall, it breaks at those joints, producing the horizontal and stair-step cracking that signals block failure.
Mortar joints have far lower pull-off strength than solid concrete, so the bond between strap and wall is the critical limit. A narrow strap concentrates the load onto a small patch of weak block and risks debonding before it ever stabilizes the wall. The 12-inch BigFoot strap spreads the same load across 50% more bonding area than an 8-inch strap, keeping the stress at the block face below the point where it lets go. On weak, weathered, or mortar-jointed walls, that extra width is the difference between a repair that holds and one that peels.
This is also why a wide 300GSM strap beats a narrow high-GSM one on block: the wall, not the fiber, is the weak point. Adding fiber density to a narrow strap does nothing if the bond to the block fails first. Spreading the load wider is what protects the bond. The unidirectional carbon fiber itself — 4,100 MPa tensile, third-party ASTM tested through our supplier — will outlast the block it is bonded to regardless of GSM.
Watch the block wall installation video →
Installation Steps
- Plan strap placement. Measure the wall and mark strap locations. Do not exceed 4 ft on-center spacing, starting 4ft from each corner. Always place straps on both sides of any window openings. Account for corners and obstructions.
- Re-point failed mortar joints first. On block walls, inspect every mortar joint in the strap path and re-tuckpoint any that are failed or crumbling before grinding. A strap bonded over a moving mortar joint bonds to something that will keep moving. This step is unique to block walls and is the most common reason a block repair fails.
- Prepare the wall surface. Using a hand grinder with the included 4.5 inch diamond cup wheel and a dust shroud with vacuum (rentable at most tool rental locations), grind a 13-inch wide path from the top of the wall to the floor at each strap location. This removes paint, efflorescence, and loose material for maximum epoxy bond.
- Vacuum thoroughly. Remove all dust from the ground areas. Dust will prevent the epoxy from bonding properly.
- Fill any cracks. Cracks at a strap location must be filled with epoxy paste or cement grout before applying the carbon fiber. The strap bonds to the surface — it cannot bridge voids beneath it.
- Apply epoxy to the wall. Mix a batch of StarTech Carbon Fiber Saturation Epoxy and apply to the wall at the strap location using the provided roller.
- Apply epoxy to the carbon fiber. Apply epoxy to the side of the strap that will bond to the wall.
- Place the strap. Press the epoxied carbon fiber strap firmly onto the epoxied wall. Use the concrete anchors to hold the strap in position during installation.
- Saturate and finish. Apply additional epoxy over the strap and use a trowel to force resin through the fabric, fully saturating all fibers. Move to the next strap location.
Tips for Carbon Fiber Block Wall Repair
1. For maximum benefit, strap a complete wall corner to corner rather than spot-repairing individual cracks.
2. Always strap both sides of every window opening — the opening creates a stress concentration in the wall.
3. Do not exceed 4 ft on-center spacing. Closer is better. If a window is 3 ft from a corner, place your first strap 3 ft from the corner beside the window.
4. Re-point failed mortar joints and fill cracks in the strap path before applying carbon fiber.
5. Cracks running under window openings can be addressed with a horizontal strap under the opening, overlapping the nearest vertical straps.
6. For stair-step cracks, apply two strap layers at the same location — one vertical and one horizontal — for maximum restraint in both directions.
7. Top-of-wall support is needed separately if the sill plate or floor joists are sliding inward. Standard hurricane ties at every joist or an under-mounted plank are better than metal top plates, which can split the sill under load. Optional top and bottom anchors are available for this kit.
8. For corner repair, install straps horizontally on the exterior at 2 to 4 ft spacing.
Common Questions About 12-Inch Carbon Fiber Block Wall Repair
When do I need 12-inch straps instead of 8-inch?
Use 12-inch straps for CMU block and cinder block walls, and for weak or weathered concrete. Block walls are hollow and fail at the mortar joints, so the wider strap is needed to spread the load across more of the weak joint system. For sound poured concrete walls, the 8-inch kit is the correct choice because poured concrete is solid through its full thickness.
What causes a block wall to bow?
Hydrostatic soil pressure from water-saturated or expansive soil pushing against the wall from outside, compounded by freeze-thaw cycles each winter in cold climates. Block walls give way at the mortar joints, producing horizontal and stair-step cracking. It develops over years and worsens progressively without intervention.
How do I address stair-step cracks in a block wall?
Re-point any failed mortar joints first, then apply two strap layers at the crack location — one vertical and one horizontal. This cross-pattern restrains movement in both directions and stabilizes the mortar-joint area where stair-step cracking occurs.
Is 12-inch 300GSM weaker than a narrow 6-inch 600GSM strap?
No. On a block wall the block is the weak point, not the carbon fiber. A 12-inch strap spreads load over more surface, lowering the stress at the block face. A narrow high-GSM strap concentrates that load and will debond from the block before the wall stabilizes. Extra fiber density does not help if the bond to the block fails first.
Do block walls need top and bottom anchors?
More often than poured walls do. A top anchor ties the strap to the sill plate where floor joists run parallel and provide no bracing; a bottom anchor pins the first block course so it cannot slide inward off the footing. If the floor slab is poured tight against the bottom course, a bottom anchor is usually not required. Optional top and bottom anchors are available for this kit — call us to discuss your wall.
Do I need metal plates at the top of each strap?
A top plate can attach the strap to the sill plate on a block wall, but plate anchors can split the sill under load. Hurricane ties at every joist or an under-mounted plank are usually better. For poured walls, top plates provide no benefit. The goal is to stop the top of the wall moving inward when the sill is not adequately connected.
How is the carbon fiber supplied and how do I cut it?
It arrives as an uncut roll. Cut each strap to your wall height with sharp scissors on any flat surface. Unidirectional fabric cuts cleanly across the width.
Can I place two straps side by side instead of one wider strap?
Yes. Two unidirectional straps side by side are equivalent to one strap of double the width — the combined bond area and fiber count are the same.
How does a unidirectional strap stop a block wall from bowing further?
Bonded to the inside face of the wall, the strap transfers lateral soil-pressure load across the full bonded area instead of letting the wall hinge at a single cracked joint. The load distributes across a much larger section of block, stabilizing the wall against further inward movement.
Limited Lifetime Warranty. Questions during your installation? Call our free technical support line at 1-866-445-3984 — our team is available throughout your project.
